PHM0M3A039

3AAA / 150lm / 8.5h


Intelligent Infrared Sensor LED Headlight, Hands-free Operation


Available in 1 colour
  • Sensor Mode Stand-by
  • Wave Hand for ON / OFF
  • Luxeon Rebel ES White LED - Up to 150 Lumens
  • 2 Operation Methods - Manual Operation or IR Sensormatic Operation
  • Intelligent IR Sensor for Cree LED allows Remote Operation when Hands are Dirty or Wearing Glove, like Fishing or Climbing
  • Rebel ES LED Smooth Dimming Control [100%-10% Brightness]
  • Rebel ES LED Focus Control Illumination [1X Flood & 4X Spot]
  • Red LED Indicator on Button shows Stand-by Status of IR Sensormatic Operation Mode
  • Additional Ø5mm Red LEDs for Night Vision; SOS-Flashing for Emergency Use
  • Separated Switches for Manual Operation and IR Sensormatic Operation
  • Water Resistant
  • Operation
  • Press the Buttons enabling Independent Control over Manual Operation or IR Sensor Operation.

    MANUAL OPERATION
    Press the Manual Operation Button to cycle through lighting modes as follow.
    REBEL LED ON > RED LEDs ON > RED LEDs SOS-FLASHING > OFF
    [At REBEL LED ON Mode, press and hold the Manual Operation Button to cycle though 100%-10% output level (blinks at 10% output), release any time for desired brightness]
    [Twist the Circular Control for REBEL LED FOCUS CONTROL]

    REBEL LED IR SENSOR OPERATION
    Press the IR Sensor Operation Button to enable functions. Red LED Indicator will light up to indicate the stand-by status of IR Sensor Operation Mode.
    REBEL LED ON > REBEL LED OFF
    [Wave hand in front of the IR Sensor slowly to cycle through ON and OFF]
    [At REBEL LED ON Mode, press and hold the IR Sensor Operation Button to cycle though 100%-10% output level (blinks at 10% output), release any time for desired brightness]
    [Press the IR Sensor Operation Button to switch off completely after use]
    *IR does not work with black rubber materials

  • Battery Type
  • 3 x 1.5V AAA Alkaline Batteries [Included]

  • Bulb Type
  • 1 x Luxeon Rebel ES White LED
    2 x Ø5mm Red LEDs

  • Size
  • 63mm x 50mm x 44mm

  • Weight
  • 108g [With Batteries]

ANSI
* Flashing mode specifications cannot be measured by ANSI FL1 standard.
Flashing mode runtime is based on measurement of battery capacity change only.
